Power Probe
DM300AUTO - Automotive Digital Multimeter
DM300AUTO - Automotive Digital Multimeter
Regular price
£342.67
Regular price
Sale price
£342.67
UK Taxes included. Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Fast shippingDispatched in 24-48h
Pro warrantyBacked by Power Probe
Expert supportReal technicians
Share
What it is
The meter that reads the verdict.
The Power Probe DM300AUTO is an automotive digital multimeter with a colour TFT display and True RMS measurement, built around the tests you run on a vehicle. Alongside voltage, current, resistance, continuity, diode, frequency and duty cycle, it adds guided battery and alternator diagnostics, a cranking voltage test, and in-place fuse-current reading — one tool for most 12V/24V electrical checks.
// Function 01
Alternator Test
Guided Normal/Smart charging test with pass/fail
// Function 02
Cranking Test
Capture the voltage drop on engine start
// Function 03
Fuse Current
Read MINI·ATC/ATO·MAXI fuses without removing them
// Function 04
True RMS Meter
V, A, Ω, diode, Hz & duty on a colour screen
Features & functions
- Colour TFT with True RMS and a 6000-count display for clear, accurate readings
- Guided Normal and Smart Alternator charging test records voltage under load and shows a 12V/24V pass or fail
- Cranking Voltage Test captures the voltage drop on start to flag a weak battery or starter connection
- Colour-coded DC voltage advises on battery and alternator condition — recharge, check regulator or replace
- Reads fuse current through MINI, ATC/ATO and MAXI fuses in place, plus in-line current to 10A (30A with probe)
- Full multimeter: DC/AC voltage to 1000V, resistance, continuity, diode and LED test, frequency and duty cycle
- Rugged CAT III 1000V / CAT IV 600V, 4 ft drop and vibration tested; runs about 50 hours on 4× AA
Read the charging system at a glance: colour-coded voltage turns raw DC volts into clear advice — battery OK, recharge, or check the alternator.
Technical specifications
| Function | Range / value |
|---|---|
| Display | Colour TFT, 6000 counts, True RMS |
| DC / AC voltage | 6 / 60 / 600 / 1000 V, ±(2% + 3D) |
| Fuse current | MINI 2–30A · ATC/ATO 1–40A · MAXI 20–80A |
| In-line current | 1 A / 10 A (up to 30 A with probe) |
| Functions | V, A, Ω, continuity, diode/LED, Hz, duty, cranking, alternator |
| Safety | CAT III 1000V · CAT IV 600V |
| Power | 4 × AA, ~50 h; auto power-off 15 min |
| Size / weight | 92.6 × 205 × 57.5 mm · 588 g |
What's in the box
1× Power Probe DM300AUTO Automotive Test Meter · 1× test lead set with alligator clips · 4× AA batteries · 1× user manual
